Which Pillow Pouch Machine Fits Your Product?
Pillow pouches — also called fin-seal sachets or 3/4-side seal sachets — are flat rectangular pouches formed from rollstock film. Shantou Dachuan's pillow-sachet line covers two platforms: a horizontal form-fill-seal (HFFS) line for 3/4-side seal sachets at medium-to-high speed (DC-228, DC-338, DC-889), and a vertical collar-type (VFFS) line for back-seal pillow bags at medium speed (DC-890B). Multi-lane variants (DC-880G, DC-880L) multiply throughput on the same horizontal platform. Choose by bag format, product type and required speed.
DC-228 / DC-338 Horizontal 3/4-Side Seal Sachet Series
The DC-228 and DC-338 series are Shantou Dachuan's horizontal form-fill-seal (HFFS) pillow-sachet platforms — forming 3-side or 4-side seal sachets directly from rollstock film. Servo-driven film feed, horizontal and vertical heat-seal jaws with PID control, and an HMI recipe system for quick bag-length and fill-volume changeover.
DC-228 Series
Horizontal 3/4-Side Seal Sachet
Horizontal HFFS line for 3-side and 4-side seal sachets. Servo film feed with electronic tension control, stainless-steel forming set, PID heat-seal jaws. Ideal for medium-speed production of snack, candy, sugar, salt, seasoning, detergent powder and pharmaceutical granule sachets.
- Bag Format
- 3-side / 4-side seal sachet
- Speed
- 40–80 sachets/min
- Best For
- Granule / powder / solid pieces
DC-338 Series
High-Speed 3/4-Side Seal Sachet
High-speed upgrade of the DC-228 platform — reinforced sealing jaws, high-frequency heating, and an optimised film-pull servo for sustained high-speed production. Designed for large-volume food, detergent and agrochemical packaging lines where throughput above 80 sachets/min is required.
- Bag Format
- 3-side / 4-side seal sachet
- Speed
- 80–150 sachets/min
- Best For
- High-volume 3/4-side seal lines
DC-889 / DC-880 Multi-Lane Sachet Series
The DC-889, DC-880G and DC-880L share the same horizontal HFFS platform but run multiple lanes side-by-side — multiplying throughput without enlarging machine footprint. DC-889 is the ultra-high-speed single-format champion; DC-880G handles granule multi-lane; DC-880L handles liquid and viscous multi-lane — all sharing the same HMI recipe system.
DC-889
Ultra-High-Speed Sachet (Powder / Granule)
Shantou Dachuan's flagship ultra-high-speed single-lane pillow-sachet line — designed for powder and granule products at throughputs above 150 sachets/min. Multi-head combination weigher paired with an ultra-fast indexing system. Built for 3-shift food, detergent and agrochemical production lines.
- Product
- Powder / granule
- Speed
- 150–300+ sachets/min
- Best For
- Ultra-high-volume powder/granule lines
DC-880G
Granule Multi-Lane Sachet (4-Side Seal)
Multi-lane horizontal HFFS platform for granule products — coffee powder, milk powder, sugar, salt, seasoning, nuts, pet food, desiccant, pesticide granule. Each lane runs an independent multi-head weigher or volumetric cup filler. Scales from 2 to 8 lanes for 200–600+ sachets/min total.
- Product
- Granule
- Speed
- 200–600+ sachets/min (multi-lane)
- Best For
- High-volume granule sachet lines
DC-880L
Liquid & Viscous Multi-Lane Sachet
Multi-lane horizontal HFFS platform for liquid and viscous products — ketchup, mayonnaise, honey, syrup, sauce, shampoo, shower gel, detergent liquid, body lotion. Piston / metering pump per lane with independent flow-metering control. Scales from 2 to 8 lanes for high-volume liquid packaging lines.
- Product
- Liquid / viscous / paste
- Speed
- 200–600+ sachets/min (multi-lane)
- Best For
- High-volume liquid/viscous sachet lines
DC-890B Vertical Collar-Type Back-Seal Pillow Bag
The DC-890B is a vertical form-fill-seal (VFFS) collar-type machine — it pulls rollstock film through a stainless-steel forming collar, shapes it into a tube, fills the tube, and heat-seals it into a back-seal pillow bag in one continuous motion. Unlike horizontal HFFS sachets, the VFFS back-seal pillow bag has no side seals and offers a smoother, more Hermetic package — ideal for powders, granules and viscous products that need a stronger, more compact seal.
Not sure which model fits? Send us a product description or sample — we will recommend the right machine type (HFFS vs. VFFS), lane count and filling unit within one business day.
Select By Industry
Shantou Dachuan's pillow pouch machines are configured for eight core industries — each with its own filling unit (multi-head combination weigher, volumetric cup, auger, piston/metering pump) and sealing profile matched to your film. Click an industry to see application examples and recommended DC-XXX model and configuration.
Need pre-made doypack, zipper or flat-bottom pouches instead of rollstock-film sachets? Those formats are pre-printed and pre-cut by your pouch supplier — the machine fills and seals only. Switch to our Premade Bag Packing Machine category for DoyPack, zipper and stand-up pouch solutions up to 50 bags per minute.
Key Components at a Glance
All Shantou Dachuan pillow pouch machines (DC-228 / DC-338 / DC-889 / DC-880G / DC-880L horizontal HFFS, DC-890B vertical VFFS) share the same Siemens-based control platform and stainless-steel contact surfaces. Each product page has detailed component breakdowns and branded part close-ups.
Shared Across All Models
- Siemens PLC + SMART 700 HMI touch screen for recipe-driven changeover
- Schneider circuit breakers, AirTAC pneumatics, Omron encoders and SMC cylinders
- SUS 304 stainless-steel product contact surfaces (food & pharma compliant)
- PID heat-seal temperature control with dual seal-bar monitoring
- End-of-film sensor, no-product sensor and mis-seal detection with auto-stop
- Hot-ribbon batch-number / date printer integrated in the seal station
- 2-year mechanical warranty + lifetime remote technical support
Model-Specific Filling Systems
- DC-228 Series — Servo film feed + volumetric cup / auger filler (HFFS, 40–80/min)
- DC-338 Series — Reinforced seal jaws + multi-head weigher (HFFS, 80–150/min)
- DC-889 — Ultra-high-speed indexing + 10/14-head combination weigher (HFFS, 150–300+/min)
- DC-880G — Multi-lane platform + multi-head weigher per lane (multi-lane HFFS, 200–600+/min)
- DC-880L — Multi-lane platform + piston/metering pump per lane (multi-lane HFFS liquid, 200–600+/min)
- DC-890B — Vertical collar-type VFFS, servo film pull, forming collar (VFFS, 30–80/min)
Click each model for full specifications, component photos, and factory video.
Frequently Asked Questions
What is the difference between horizontal HFFS and vertical VFFS pillow pouch machines?
Which model should I choose?
What bag formats and film types are compatible?
What is the output speed and filling accuracy?
How long does a format changeover take?
What are the lead time, payment, and shipping terms?
What industries does Shantou Dachuan serve with pillow pouch machines?
Ready to Configure Your Pillow Pouch Line?
Tell us your product type, fill weight, bag format (3/4-side seal sachet or back-seal pillow bag), film material and required daily output. We will match you to the right DC-228/338/889/880G/880L or DC-890B configuration and return a quotation within one business day. All machines are CE certified, factory-tested in Shantou with your film roll, and shipped with full English documentation.
